400VX
214-238-7979
1250 Champion Circle STE100, Carrollton TX 75006
Features & Specifications:
STANDARD WHEELS INCLUDED!
Electric Start Operation.
On Demand 2 WD / 4 WD Operation with Differential
Lock
Shaft Drive.
Dual Hydraulic Disc Front Brakes.
Hydraulic Disk Rear Brake.
Heavy Duty Cargo Bed.
Large, Rugged All Terrain Tires.
3500 lb. Winch OPTIONAL - ADDITIONAL $299.95
Parts & Service readily available.
Length/ Width/ Height 105.5” X 61.0” X 73.6”
Weight 1197 lbs
Load Capacity 882 lbs.
Cargo Bed 350 lbs.
Pulling Capacity 1212 lbs.
Trailer Tongue Weight 110 lbs.
Ground Clearance 11.8”
Wheel/Tire Size AT25 x 8-12 (F), AT25 x 10-12 (R)
Wheelbase 72.0”
Engine Type Liquid Cooled 4 Stroke
Engine Displacement 393cc
Bore & Stroke 84.5mm x 70mm
Compression Ratio 9.3:1
Ignition CDI
Fuel Capacity 6.86 gal
The 393cc single-overhead cam EFI engine produces power efficiently
On demand four-wheel drive backed by a differential lock
Double-wishbone independent front and rear suspensions with adjustable shocks for a safe ride.
Automatic CVT transmission shifts smoothly into forward, neutral and reverse
Dual-front and rear-ventilated hydraulic disc brakes stop you on a dime
Heavy-duty metal frame and racks securely hold your gear
All-terrain tires stay planted to the ground for ultimate traction
Haul up to 1,212 lbs. with a standard UTV hitch and 2" adapter
882-lb. payload capacity
3,500-lb winch helps get you out of sticky situations
